AKG P4 Dynamic Instrument Microphone for Drums and Amps with H440 Bracket

AKG P4: A Compact Dynamic Instrument Microphone With Its Own Bracket

The AKG P4 is a cardioid dynamic instrument microphone with a compact body, an even 40 Hz to 18,000 Hz response and 152 dB SPL of level handling. It ships with an H440 adapter plate, an external mounting bracket that lets the microphone sit on a drum rim or in a tight stage position rather than only on a stand. Its element is dynamic, so no phantom power and no battery are required anywhere in the chain, and sensitivity is 2.5 mV/Pa into a 500 ohm electrical impedance. A built-in humbucking coil rejects the electromagnetic interference that surrounds a stage. It is the instrument microphone to specify when the position is tight and the source is loud.

The H440 Adapter Plate and Mounting on a Drum

An H440 adapter plate is supplied alongside the microphone's own integrated stand adapter, giving two entirely different mounting routes from one box. Stand mounting is straightforward but consumes floor space and boom reach, which becomes a real problem on a drum riser where a snare, two toms, a hi-hat and a ride already occupy every available angle. The adapter plate instead lets the microphone be carried on a rim clamp or bracket close to the drum head, removing a boom stand from the kit entirely and taking the microphone with the drum whenever the kit is moved. A touring drum technician setting up a five-piece kit in forty minutes gains back both the space and the setup time that four separate boom stands would have consumed.

Isolation Between Drums Inside a Crowded Kit

Isolation between adjacent sources is what a cardioid pattern buys on a drum kit, and it matters more than any tonal characteristic when eight microphones share three feet of space. Cardioid pickup is most sensitive directly in front of the capsule and least sensitive directly behind it, so a microphone aimed down at a snare head naturally rejects the hi-hat sitting behind and above it. Cleaner separation means a mix engineer can equalize the snare channel without also equalizing the hi-hat, and a gate on the tom channels will actually open on the toms rather than on every cymbal crash. Live engineers working with limited channel processing get most of the way to a controlled drum sound through microphone pattern and placement alone.

Handling of 152 dB SPL for Snare, Toms and Cabinets

Handling of 152 dB SPL means the capsule and its electronics cope with the pressure directly above a struck drum head without any pre-attenuation stage. Peak levels an inch or two from a snare batter head are far higher than most engineers assume, and a microphone short of headroom does not distort on the sustained tone but on the initial attack transient, which is heard as a hard edge or a spitting quality on the stick hit rather than as obvious overload. Loud guitar cabinets present the same problem in a different form, with a sustained level rather than a transient peak. A rehearsal room drummer, a studio engineer close-miking toms, and a guitarist recording an amplifier at performance volume all rely on the same headroom figure.

A Response Spanning 40 Hz to 18,000 Hz Plus the Humbucking Coil

A response spanning 40 Hz to 18,000 Hz is described as flat and even, which is a deliberately different design goal from a microphone voiced with a bump for one specific source. Starting at 40 Hz keeps subsonic stage rumble and mounting-borne thump out of the channel, while reaching 18,000 Hz preserves the stick attack on a snare, the reed detail in a saxophone and the top end of a cymbal-adjacent tom. A built-in humbucking coil handles a separate problem entirely: any coil of wire acts as an antenna for the alternating magnetic fields radiated by lighting dimmers, power distribution and amplifier transformers, and this winding is arranged so that interference cancels while the audio passes through untouched. Clamping a microphone to a drum rim under a lighting truss with a bass rig two feet away is exactly the situation it addresses.

Output, Impedance and Where the P4 Ends Up

Output is a balanced 3-pin XLR male connection at a 500 ohm source impedance into a recommended load of 2,000 ohms or more, ordinary behavior for any console, stage box or audio interface input. Supplied in the box are the microphone, the H440 adapter plate and a microphone bag, with the stand adapter integrated into the body itself so nothing else is needed to rig it. The applications that follow from a compact, high-headroom cardioid dynamic are consistent: snare top and bottom, rack and floor toms, congas and hand percussion, guitar and bass amplifier cabinets, wind instruments and saxophone, and brass section spot positions. Drum technicians, studio engineers, rehearsal rooms and small-venue crews all buy them in multiples for the same reason, which is that one microphone type covers most of a stage.
