Rohn 45GSR110R290 Complete Tower Assembly

Home Rohn 45GSR110R290 Complete Tower Assembly
$59,875.00

290' heavy-duty guyed tower rated for 110 MPH, solid steel legs, 4-bolt flanges, 30 sq. ft. load, galvanized construction, and 10' modular sections

Availability: Special Order, Please Allow 2-4 Weeks For Delivery
SKU
45GSR110R290



Features:

  • Tower height reaches 290 feet with heavy-duty rating
  • Engineered for 110 MPH 3-second wind gusts with 30 sq. ft. antenna load
  • Constructed from solid round steel legs for high strength
  • 4-bolt flange section connectors provide robust guying joints
  • Includes 10' modular tower sections for easier transport and install
  • Galvanized after fabrication to maximize rust and corrosion resistance
  • Double-bolted joints and solid zig-zag cross bracing throughout
  • Compatible with various base types: anchor bolt, hinged, or cast-in concrete

Engineered For Demanding Tower Installations

The Rohn 45GSR110R290 is a 290-foot complete guyed tower kit designed to meet heavy-duty communication and broadcasting needs. This tower is part of Rohn’s 45GSR series, engineered with solid round steel legs and a robust 4-bolt flange system to handle taller installations in tough environments. Rated to withstand 110 MPH 3-second wind gusts with a maximum antenna load of 30 square feet, this tower offers a proven combination of strength, stability, and modular construction.

Built For Structural Integrity and Wind Load Resilience

This 290' tower configuration provides secure height for demanding applications such as cellular networks, ham radio, wireless ISPs, and broadcast antennas. The guyed structure allows for wide antenna loading while maintaining structural reliability even in high-wind zones. Rohn’s galvanization process ensures each steel component is protected against corrosion, making this tower well-suited for long-term outdoor use in variable weather conditions.

Modular 10-Foot Sections With Flexible Base Options

Constructed from 10-foot standard modular sections, the Rohn 45GSR110R290 is straightforward to transport and install. The tower supports multiple base options to accommodate different foundation setups, including cast-in-place concrete, hinged bases, or base plates with anchor bolts. The system’s modularity allows for precise adjustments during installation and provides flexibility for future reconfiguration or tower extensions.

Heavy-Duty Bracing and Connection Design

The tower’s double-bolted joints, continuous solid rod bracing, and strong zig-zag cross members all contribute to an assembly that prioritizes durability and safety. The 4-bolt flange connection system provides a rugged and reliable interface between tower sections, minimizing movement and increasing the tower’s ability to maintain structural integrity under stress.

Trusted Solution For Broadcast, Telecom, and Utility Use

Engineered for versatility, this complete tower kit is a trusted solution for a range of professional users, including broadcast engineers, utility providers, and network infrastructure contractors. With proven Rohn quality and decades of real-world performance, the 45GSR110R290 is ideal for critical long-term installations where height, load capacity, and resilience matter most.

More Information
MPN 45GSR110R290
Color Silver
Brand Rohn Products
Product Condition New
Availability Out of Stock
