Compact Isolated Power Supply Bundle for Misha, Delivers Isolated 9V Center-Negative Power (Min 400 mA), 4 Isolated Outputs (2 Fixed 9V, 2 Switchable 9/12/15/18V) at 660 mA, 24W with Included 18V Adapter, Flex Cables Included
This Eventide bundle packages the compact PowerMini isolated power supply to power the Misha interval-based instrument outside a Eurorack case. The Misha needs a specific isolated 9V feed to run on a desk or stage, and this kit delivers exactly that, correctly and quietly. For players who want to take the Misha out of the rack, it is the power solution that makes standalone use simple.
Outside a Eurorack case, the Misha requires isolated 9V DC power, center-negative, at a minimum of 400 mA through a 2.1 by 5.5 mm barrel connector. The PowerMini supplies exactly this from an isolated output, so the instrument gets clean, correctly-polarized power rather than a mismatched adapter that could fail or introduce noise. Getting the polarity, voltage, and current right is the difference between a Misha that runs reliably and one that will not power up. This bundle removes that guesswork entirely.
The PowerMini itself is a super-compact isolated supply measuring 2.9 by 3.5 by 1.0 inches, with four individually isolated outputs, two fixed at 9V and two switchable between 9, 12, 15, and 18V, each up to 660 mA. Beyond powering the Misha, those spare outputs can run a couple of pedals, making the kit useful for a small hybrid rig. Running from the included 18V universal adapter, it delivers a full 24W, and the appropriate flex cabling for the Misha is included. It is a quiet, capable supply that happens to be perfectly matched to the Misha.
This bundle is for Misha owners who want to use the instrument as a standalone or tabletop unit and need the correct isolated power to do it. It also suits players who want a compact supply that can power the Misha plus a pedal or two in a small portable rig. If your Misha is leaving the Eurorack case, this is the power kit designed to go with it.
| MPN | 427380 |
|---|---|
| Color | Black |
| Input | 18V DC from included universal adapter (AC mains) |
| Power Source | AC Mains (via included 18V adapter) |
| Size | PowerMini: 2.9" x 3.5" x 1.0" |
| Form | Pedal Power Supply Bundle |
| Output | 4x 9-18V DC (incl. 9V center-negative for Misha) |
| Channels | 4 isolated DC outputs |
| Output Power | 24W total |
| UPC / EAN | 840694002580 |
| Brand | Eventide |
| Product Condition | New |
| Availability | Out of Stock |
| Type | Compact isolated power supply bundle configured to power the Misha |
| Misha Requirement | Isolated 9V DC, center-negative, min 400 mA, 2.1 x 5.5 mm barrel |
| Total Power | 24W (with included 18V adapter) |
| Outputs | 4 isolated outputs |
| Fixed Outputs | 2x 9V, 660 mA |
| Switchable Outputs | 2x 9/12/15/18V, 660 mA |
| Isolation | Individually isolated outputs |
| In the Box | PowerMini supply, 18V universal adapter, flex DC cables (incl. Misha cable), documentation |
