EAW MKD864 Passive 2-Way Loudspeaker (White)

High-performance loudspeaker for permanent installs
The EAW MKD864 WHITE is a passive two-way loudspeaker designed for fixed installation environments that demand high output, broad pattern control, and excellent sound fidelity. Engineered for music venues, clubs, retail environments, and stadium systems, it delivers premium performance in a compact form factor. The MKD864 combines rugged construction with professional-grade components, making it ideal for system designers looking for reliable, scalable solutions that meet a wide range of acoustic requirements.

Compact dual 8-inch design with extended frequency response
This model features dual spaced 8-inch low-frequency cone transducers paired with a 1-inch exit compression driver mounted on a 60° x 45° constant directivity horn. This configuration allows the MKD864 to provide extended low-frequency response and articulate highs, delivering clear vocals and punchy bass without distortion. The system benefits from EAW’s beamwidth-matched crossover, ensuring seamless integration between the LF and HF components across the listening area.

Precision pattern control for challenging environments
Thanks to the horn-loaded compression driver and optimized driver spacing, the MKD864 offers broadband pattern control that ensures consistent off-axis response. This helps maintain tonal balance even in reflective or acoustically complex spaces. Whether you're installing in a reverberant restaurant, a house of worship, or a tightly packed music venue, the MKD864 provides focused, controllable sound where it matters.

Versatile installation and rigging options
The MKD864 WHITE is equipped with 16 integrated M10 mounting points, supporting both vertical and horizontal orientation using optional U-brackets and mounting accessories. This provides flexibility for system integrators designing multi-speaker configurations or distributed audio systems. With its curved front grille and clean white finish, the MKD864 blends into architecturally sensitive spaces without compromising on sonic performance.

Reliable passive operation with robust construction
Operating in full passive mode, the MKD864 simplifies system wiring and requires no external DSP processing for crossover alignment. The enclosure is built from birch plywood and finished in a durable white paint, with a powder-coated steel grille that provides protection without impeding acoustic output. The result is a speaker that performs reliably under daily use in demanding commercial installations.
