EAW MKD1064 Installation Speaker (White)

High-Output Installation Speaker for Large Venues and Demanding Audio Environments
The EAW MKD1064 WHITE is a 1000W passive 2-way installation loudspeaker built for high-performance audio in permanent or semi-permanent installs. Designed for stadiums, concert halls, houses of worship, and music clubs, it delivers full-range clarity, broadband pattern control, and serious output. This model features dual 10-inch low-frequency drivers and a 1.4-inch exit, 4-inch Neodymium compression driver, delivering rich low-end and detailed highs. The white finish ensures discreet visual integration in architecturally sensitive spaces, making it a top choice for AV integrators and system designers alike.

Precision Pattern Control with QX-series Technology
Drawing on technologies developed in the flagship QX series, the MKD1064 WHITE features a rotatable large-format horn with a nominal beamwidth of 60° horizontal by 45° vertical. Its beamwidth-matched crossover technology enables the low-frequency transducers to operate an octave lower than conventional designs, resulting in greater coherence and smoother frequency transitions. This design enhances intelligibility in reverberant spaces and ensures accurate coverage where it matters most.

Exceptional Output with Low Distortion at High SPL
Engineered for high-output reinforcement, the MKD1064 WHITE achieves a maximum SPL of 144 dB (12 dB crest factor) and a flat SPL of 138 dB (6 dB crest factor). It handles an extended frequency range of 57Hz to 20kHz with an axial sensitivity of 93 dB. Whether you're reinforcing speech, music, or complex multimedia content, the MKD1064 maintains clarity and dynamics, even at demanding volumes.

Flexible Mounting and Configuration Options
This loudspeaker supports both passive and bi-amplified operating modes, making it adaptable to different system requirements. It includes 12 M10 mounting points for secure rigging in vertical or horizontal orientations. Compatible with optional U-brackets and eyebolts, it’s ready for overhead, wall, or custom rigging configurations. The input terminal block ensures secure and simple connections for permanent installations.

Weather-Ready Design for Indoor and Outdoor Use
With IP56-rated weather resistance and a rugged Baltic birch enclosure, the MKD1064 WHITE is built for real-world conditions. The durable white textured finish and curved front design make it suitable for environments where visual impact must be minimal. Whether it’s mounted inside a performance venue or exposed in an outdoor stadium, this speaker is engineered for long-term reliability and acoustic performance.
